Check Specification & Cross-references
Fortpro is a trusted leader in the development and manufacturing of premium-quality truck parts designed to meet the demands of semi-trucks and heavy-duty trucks. Renowned for innovation, durability, and reliability, Fortpro products are engineered to enhance performance, safety, and efficiency across a wide range of trucking applications.
Whether you're seeking OEM replacement parts or upgrades, Fortpro provides a diverse selection of components backed by a global reputation for quality and innovation. Trust Fortpro for the parts you need to keep your vehicles on the road longer and stronger.
Specific attributes
| LeftF265858 | RightF265859 | |
|---|---|---|
| Basic Part Information | ||
| Alternate Part Name | Left Hand Tie Rod End, Tie Rod End Socket | Right Hand Tie Rod End, Tie Rod End Socket, Steering Tie Rob End |
| OEM Part Number | R230068 | R230069 |
| Dimensional/Physical Attributes | ||
| Rod Thread Direction | Left Hand | Right Hand |
| Cross-references | ||
| Cross-references | 00698571, 1006148, 140TR109, 15515804, 1668407C91, 1681457C91, 310222, 310222E, 3744497, 438368C91, 507837C91, 698571, 8235-R230068, 8235R230068, A3144E525, ARE9989, D0HZ3A131A, D0HZ3A131D, E-4614, E11004, E3HZ3A131A, E4614, E4HZ3A131A, EM99890, ES3217L, ES423L, FTR423L, FTR8407, L20SV8100D12, L20SV8102D12, L20SV8102D19, L20SV8102K12, L24SV5043A12, L24SV5043A14, PAI9989, SP692243, 1006149, R230068 | 1006149, 140TR110, 15515805, 1668408C91, 310223, 310223E, 370240005, 370245010, 3744496, 41035BLW0, 438369C91, 507838C91, 698572, 8235-R230068, 8235R230068, A3144D524, ARE-9988, ARE9988, D0HZ3A130A, E3HZ3A130A, E4HZ3A130A, E4HZ3A130B, EM99880, ES3218R, ES423R, ES423RI, FTR423R, FTR8408, L20SV8101D12, L20SV8101D15, L20SV8103D12, L24SV5042A12, L24SV5042B12, L24SV5043A12, TE2030, V1091563, 1006148, L24SV4000H11, L24SV5042A14, R230068, SP692244 |
Common Attributes14 attributes
| Basic Part Information | |
|---|---|
| Product Line | Steering Components |
| Category Name | Tie Rods & Ends |
| Part Type | Tie Rod End |
| Application/Fitment Attributes | |
| Application Type | Semi-Trucks, Heavy Duty Trucks |
| Mounting Location | Front Axle |
| Dimensional/Physical Attributes | |
| Material | Forged Steel |
| Rod End Thread Size | 1.125 in.- 12 |
| Stud Center to Rod End Length | 5.44 in. |
| Stud Thread Diameter | 0.875 in. - 14 |
| Taper Diameter - Large | 1.102 in. |
| Taper Diameter - Small | 0.967 in. |
| Taper Length | 1.08 in. |
| Technical/Performance Attributes | |
| Tie Rod Design Type | Straight |
| Packaging / Logistics Attributes: | |
| Net Weight | 3.34 lb. |
Intended Application
- Steering System: Tie Rod Assembly (Front Steer Axle) Compatible with Mack CXN, CXU models (2012)
- Meritor: R230068
- Dana: SP692243, 140TR109
- Dayton Parts Batco: 310222
- Eaton: L24SV5043A12, 1006148, 1006149
- Federal Mogul: ES3217L, ES423L, L24SV5043A12, L24SV5043A14
- Flagg: ES423L
- Marmon: A3144E525, L24SV5043A12
- Moog: ES423L
CrossReference (F265859 Right Side):
- Meritor: R230069
- Dana: SP692244, 140TR110
- Dayton Parts Batco: 310223
- Eaton: L24SV5042A12, 1006148, 1006149
- Federal Mogul: ES3218R, ES423R, L24SV4000H11, L24SV5042A14
- Flagg: ES423R
- Marmon: A3144D524, L24SV5042A12
- Moog: ES423R
Dimensions Not Available.
