Check Specification & Cross-references
Fortpro is a trusted leader in the development and manufacturing of premium-quality truck parts designed to meet the demands of semi-trucks and heavy-duty trucks. Renowned for innovation, durability, and reliability, Fortpro products are engineered to enhance performance, safety, and efficiency across a wide range of trucking applications.
Whether you're seeking OEM replacement parts or upgrades, Fortpro provides a diverse selection of components backed by a global reputation for quality and innovation. Trust Fortpro for the parts you need to keep your vehicles on the road longer and stronger.
| Basic Part Information | |||
|---|---|---|---|
| Product Line | Steering Components | Category Name | Power Steering Pump |
| Part Type | Steering Pump | Alternate Part Name | Hydraulic Power Steering Pump |
| Model | V20 F | OEM Part Number | V20F 1P8P 38D5H 22 |
| Application/Fitment Attributes | |||
| Application Type | Semi-Trucks, Heavy Duty Trucks | Inlet Port Thread Size | 1-1/4 NPT |
| Mounting Type | 2 Bolt Flange SAE-A SIZE | Outlet Port Thread Size | 1/2 - NPT, 3/4 -16 NPT |
| Dimensional/Physical Attributes | |||
| Material | Cast Iron | ||
| Technical/Performance Attributes | |||
| Max Operating Speed | 2800 rpm | Max Relief Pressure | 2000 psi |
| Nominal Flow Rate | 8 US gpm @ 1200 rpm | Operating Temperature Range | 0 deg. C – +80 deg. C |
| Pump Displacement | 26.50 cm³/rev | Shaft Rotation Direction | Right-Hand |
| Shaft Type | 11-Tooth Spline | Volumetric Efficiency | ? 90 – 92 % |
| Packaging / Logistics Attributes | |||
| Package Length | 7.00 in. | Package Width | 8.00 in. |
| Package Height | 8.00 in. | Net Weight | 21.84 lb. |
- Mack: V20F1P8P38D5H22, 38QC367P26
- PAI: EM-38820, ESP-3955
Dimensions Not Available.
