Fortpro F245575 Cab Air Spring is made with high quality materials, including rubber and steel, which provide durability and resistance to wear. These air springs are designed to withstand heavy loads and offer greater stability and comfort while driving
Fortpro is a trusted leader in the development and manufacturing of premium-quality truck parts designed to meet the demands of semi-trucks and heavy-duty trucks. Renowned for innovation, durability, and reliability, Fortpro products are engineered to enhance performance, safety, and efficiency across a wide range of trucking applications.
Whether you're seeking OEM replacement parts or upgrades, Fortpro provides a diverse selection of components backed by a global reputation for quality and innovation. Trust Fortpro for the parts you need to keep your vehicles on the road longer and stronger.
| Basic Part Information | |||
|---|---|---|---|
| Product Line | Suspension | Category Name | Air Springs and Bags |
| Part Type | Cabin Air Spring | Alternate Part Name | Super-Cushion Sleeve Air Spring, Cab Suspension Air Spring, Tapered Sleeve Air Spring, Cab Air Bag |
| OEM Part Number | W02-358-7017 | ||
| Application/Fitment Attributes | |||
| Application Type | Heavy Duty Trucks, Semi-Trucks | VMRS Code | 016-008-000 |
| Dimensional/Physical Attributes | |||
| Material | Reinforced Rubber | Air Inlet Inside Thread | 1/8-27 NPTF |
| Bottom Plate Alignment | Parallel | Bottom Plate Diameter | 2.12 in. |
| Bottom Plate Inside Thread | 1/2-13 UNC | Mounting Hole Configuration - Bottom | 1 |
| Mounting Hole Configuration - Top | 1 | Piston Height | 3.38 in. |
| Top Plate Diameter | 2.65 in. | ||
| Technical/Performance Attributes | |||
| Air Spring Type | Sleeve | Collapsed Length | 4.00 in. |
| Extended Length | 15.18 in. | ||
| Packaging / Logistics Attributes: | |||
| Net Weight | 1.09 lb. | ||
| Additional Information | |||
| Intended Application |
|
||
- Automann: ABSZ707017
- Dayton Parts Batco: 1S5055, 3537017
- Firestone: 7017, W023587017, W02-358-7017
- Goodyear: 1S5055
- Mack: 227QS38
