Fortpro Type 3636 Brake Chamber - Standard Stroke, Sealed | F224796
Fortpro Type 3636 Brake Chamber - Standard Stroke, Sealed | F224796
SKU: F224796
Availability: In Stock
Stock Level: More than 50 available.
Shipping: Calculated at Checkout
About this Item
- Rugged Service Housing. 9 Gauge Steel and Powder-coated Finish for High Resistance to Fatigue and Corrosion
- Manufactured Under ISO/TS 16949:2009 Our Brake Components Meet and Exceed International Standards.
- Our Air Brake Components have been Passed the Following Tests: Salt Spray Test, Leak Tightness, Endurance Test
- Standard Stroke with Length: 3"
- Type 36/36 - Push Rod Length: 9"
Description
Description
Specifications
Specifications
- Brand: Fortpro
- Vehicle Type: Semi-Trucks / Heavy Trucks
- Product Department: Brakes
- Product category : Brake Chambers
- Part Type: Air Brake Chamber
- Also Known as:: Brake Canister / Brake Can / Air Brake Canister / Brake Pod / Brake Pots
- Chamber Type: Spring Brake Chamber
- Model: Type 3636, T36/36, T-36/36, 36/36
- Stroke: Standard Stroke
- Stroke Lenght: 3 in.
- Outside Diameter (O.D.): 9.10 in.
- Brake Type Support: Drum
- Serviceability: Sealed
- Push Rod Thread: 5/8-18 UNF-2A
- Push Rod Length: 9 in.
- Service Port: 3/8-18 NPTF
- Emergency/Release Port: 3/8-18 NPTF
- Port Angle: 90°
- Clevis Included: Included
- Clevis Mounting: Threaded
- Maximum Pressure: 150 PSI
- Mounting Bolt Thread: 5/8-11 UNF-2A
- Mounting Bolt Length: 1.50 in. (38.1 MM)
- Brake System Compatibility: S-Cam
- Chamber Style: Double Diaphragm
- Service Chamber Joint Type: Single Clamp Band
Cross-references
Cross-references
- Automann: 179.SB3636
- Bendix: 800833, 5007134
- Euclid: E-GC3636
- Flagg: 3636GC
- Haldex: GC3636
Manufacture Standards:
Manufactured under ISO/TS 16949:2009 our brake components meet and exceed international standards.
Our air brake components have been passed the following tests:
- Salt spray test
- Leak tightness
- Endurance test
