| Basic Part Information | |||
|---|---|---|---|
| Part Type | Air Brake Chamber | Alternate Part Name | Brake Canister / Brake Can / Air Brake Canister |
| Model | Type 2424, T24/24, 24/24, 24-24 | ||
| Application/Fitment Attributes | |||
| Application Type | Heavy Duty Trucks, Semi-Trucks | Brake System Compatibility | S-Cam |
| Brake Type | Drum | Chamber Style | Double Diaphragm |
| Chamber Type | Spring Brake Chamber | Clevis Mounting Type | Threaded |
| Emergency Port Thread Size | 3/8-18 NPTF | Mounting Bolt Length | 1.57 in. |
| Mounting Bolt Thread Size | 5/8-11 UNF-2A | Outside Diameter (O.D.) | 7.50 in. |
| Push Rod Length | 9 5/8" | Push Rod Thread Size | 5/8-18 UNF-2A |
| Service Chamber Joint Type | Single Clamp Band | Service Port Thread Size | 3/8-18 NPTF |
| Technical/Performance Attributes | |||
| Clevis Yoke | Included | Maximum Operating Pressure | 150 PSI |
| Port Orientation | 90° | Serviceability | Sealed |
| Stroke Lenght | 2.25 in. | Stroke Type | Standard Stroke |
- Bendix: NT2430STD78
- Euclid: E-GC2424
- Fleetpride: FLTC2424SB20
- Flagg: 2424GC
- Haldex: GC2424
- Mack: 19QE410A
Dimensions Not Available.
